Model No : PIAF 12RE
Mtandt
brings a range of self-propelled vertical mast boom lifts to make accessing
heights safe and reliable with its design, build and features. In addition, the indoor lift provides a stable and safe working environment for
the working personnel.
The battery-driven aerial lift is highly portable and easy-to-store that will help
you fix challenging indoor and outdoor tasks at heights with ease. In addition,
it allows you to work around obstacles conveniently, enhancing productivity at
the worksite.
The electric
mast boom lift provides a
lifting capacity of 200kg, with smooth, controlled movements and a powerful
drive. The impressive turntable rotation with zero tail swing and horizontal
outreach allows easy operation on the fragile and outdoor stabilised ground in
tight spaces.
The vertical platform is an ideal piece of equipment across industries to match applications such as masonry, insulation, electricity, HVAC, plumbing, industrial maintenance, mass distribution, logistics, events, and more.
The vertical
boom lift is equipped
with a motion alarm, anti-crushing system, platform with protection bar,
overload sensor, hour meter, on-board diagnostic colour LCD console and other
state-of-the-art features to make working at height safe for the working personnel.
Rent vertical boom lifts or buy them as per your worksite
requirement. Enquire now.
| Model No | PIAF 12RE |
|---|---|
| Working Height | 11.83 |
| Power Type | Electric |
| Platform Height (m) bhhjkk | 9.83 |
| Max Horizontal Outreach (m) | 5.10 |
| Platform Size (LxW) | 0.8x0.9 |
| Machine Weight (kg) | 4350 |
| Platform Capacity (kg) | 200 |
| Ground clearance (m) | .082 |
| SWL (Kg) | 200 |
| Power source (k.w.) | Battery |
| Gradeability | 30 |
| Max Lifting Height (m) | 0 |
| Max Lifting Capacity (Kg) | 0 |
- Non-Marking Rubber Wheels
- Platform with Protection Bar
- 200kg Load Capacity
- 48V 260 Ah Battery
- Centralized Battery Filling
- On-Board H/F Charger
- Non-Continuous 352° Turret Rotation
- 30% Gradeability
- Possible To Work at Maximum Height
- On-Board Diagnostic Colour LCD Console
- Sling and Tow Rings
- Battery Charge Indicator
- Tilt Indicator with Alarm
- Overload Sensor
- Flashing Lights
- Hour Mete
- Easy Access to the Platform by an Entry Gate
- Compressed Air Line
- Power Supply in the Platform
- Automatic 110 / 220 V Charger
- Movement Cut Off When Tilt > 2°
- Motion Alarm
- Food Grade Oil
- Biodegradable Oil
- Anti-Crushing (ACS) System
- Customer Colour (S) Paint
| No. | Name |
|---|---|
| 1 | Inspection |
| 2 | Maintenance |
| 3 | Repair |
| 4 | Tuck Pointing |
| 5 | Masonry |
| 6 | Water Proofing |
| 7 | HVAC |
| 8 | Plumbing |
| 9 | Logistics |
| 10 | Industrial Maintenance |
